– Adopt high energy saving technology
– Crater voltage and crater current control are possible.
– 3 kinds of applicable wire diameters are available. Secondary short circuit protection is the standard function.
– Fresh tip treatment and burn back time control are realized.
– Working range can be expended by welding cable extension.
– The wire feeder of RX1 machines is interchangeable to KR2’s
| Control model | IGTB Inverter |
| Rated input voltage (V) | 380 – 3PH (50/60Hz) |
| Rated input power (KVA) | 13,2 |
| Rated output current (A) | 50 – 430 |
| Rated output voltage (V) | DC 16.5 – 35.5 |
| Rated duty cycle (%) | 60 |
| Welding wire diameter (mm) | 0.8/1.0/1.2 |
| Control method | Digital |
| Net weight (Kg) | 52 |
- MIG gun
- Earth cable with clamp x 3M
- CO2 Regulator
- Separate wire feeder with control cable x 1.8M
