- Duty cycle is up to 100%
- Both arc current and drive current can be adjusted continuously
- Automatic compensation for voltage fluctuation, can work normally against input voltage fluctuation
- Advanced control technology, welders can preset welding parameters accurately
- Widely used in shipbuilding, boiler, chemical vessel, bridge girder, lifting equipment and metallurgy industries
- Suitable for carbon steel, stainless steel, heat-resisting steel and alloy metal welding
| Rated input voltage (V) | 3PH AC380±15% |
| Rated input power (KVA) | 68 |
| Rated input current (A) | 104 |
| Rated output | 60-1250 |
| No-load voltage (V) | SWA:90±10% MMA:75±10% |
| Rated duty cycle (%)(40°C | 100 |
| Efficiency (%) | 80 |
| Protection class | IP21 |
| Insulation class | F |
| Output characteristic | decrease characteristic / flat characteristic |
| Net weight (Kg) | 107.6 |
- Earth cable with clamp x 5M
- Tractor
- Control cable x 10M
