| Welding range | Ø 2-10 mm |
| Welding material | steel, stainless steel, aluminium, brass |
| Welding method | capacitor discharge |
| Welding time | 1-3 ms |
| Capacitance | 90000 µF |
| Charging voltage | 60-200 V, continuously adjustable |
| Charging energy | 1800 Ws |
| Power source | capacitor battery |
| Mains plug | earth contact plug according to DIN 49441 |
| Mains supply | 230 V (+/- 10%), 2 A, 50/60 Hz (convertable to 115 V (+/- 10%), 4 A, 50/60 Hz) |
| Mains fuse external | 10AT |
| Protection | IP 21 |
| Weight | 13.5 kg |
| Item number | B-90-30-2030 |
| Suitable welding guns | PKM-1B, PHM-1A, PIM-1B |
