-Advanced IGBT inverter technology delivers superior TIG performance
-Support TIG/MMA function
-With HF TIG arc starting, allows to strike the arc easily with high frequency and make it easy to establish an arc under a variety of conditions.
-Compact and portable, high efficiency and energy saving
-Easy arc starting, small splashing, low noise, great penetration and aesthetic appearance of welding seam
-Overheat over current, under voltage protections are available
-Energy saving- compared with the traditional TIG machine more effcient.
|
Rated input voltage (V) |
3PH AC380±15% |
|
Rated input power (KVA) |
6,3 |
|
Rated input current (A) |
9.6 |
|
Rated output |
20V/250A |
|
Output current(A) |
TIG:10-250 MMA:20-220 |
|
No-load voltage (V) |
60±5 |
|
Rated duty cycle 40 (%) (40°C 10min) |
250A |
|
Rated duty cycle 100 (%) (40°C 10min) |
158A |
|
Efficiency (%) |
80 |
|
Protection class |
IP21 |
|
Insulation class |
F |
|
Net weight (Kg) |
13 |
- TIG torch
- Welding cable with electrode holder x 1.8M
- Earth cable with clamp x 1.2M
