-Advanced IGBT inverter technology delivers superior TIG performance
-Multifunction: DC MMA, DC TIG, Pulse TIG
-Detailed adjustment parameters lead to more accurate performance such as pre-flow, gas delay, current slow up, current decay, frequency ratio and so on
-2T/4T Function selectable on the front panel
-Remote control function is available, remotely controlling your current level with a foot pedal
-Energy saving- compared with the traditional TIG machine and more efficient.
|
Rated input voltage (V) |
3PH AC380±15% |
|
Rated input power (KVA) |
18,8 |
|
Rated input current (A) |
29 |
|
Rated output |
30V/500A |
|
Output current(A) |
TIG:5-500 MMA:20-500 |
|
No-load voltage (V) |
60±5 |
|
Rated duty cycle 40 (%) (40°C 10min) |
500A |
|
Rated duty cycle 100 (%) (40°C 10min) |
316A |
|
Efficiency (%) |
80 |
|
Protection class |
IP21 |
|
Insulation class |
F |
|
Net weight (Kg) |
34 |
- TIG torch
- Welding cable with electrode holder x 1.8M;
- Earth cable with clamp x 1.2M;
