- IGBT technology, the core adopts advanced IGBT inverter device, high frequency
- Digital meter to preset and display welding current
- Anti-stick, adjustable hot striking, easy to strike the arc, stable arc welding, deep weld pool and good welding appearance.
- VRD function is optional, which is safe for welders
- Excellent performance, cart be used for welding with cellulose electrode
- Over current, over heat and under voltage protection is available
- Smaller, lighter and portable, this equipment is protected by a solid metal casing
- Energy saving-compared with the traditional SMAW machine and more efficient
- Suitable for welding the carbon steel, stainless steel, low alloy steel and other metals.
|
Rated input voltage (V) |
1PH AC220±15% |
|
Rated input power (KVA) |
8 |
|
Rated input current (A) |
36 |
|
Rated output |
200A/28V |
|
Output current(A) |
20-200 |
|
No-load voltage (V) |
68±5 |
|
Rated duty cycle 30 (%) (40°C 10min) |
200A |
|
Rated duty cycle 100 (%) (40°C 10min) |
110A |
|
Efficiency (%) |
70 |
|
Protection class |
IP21 |
|
Insulation class |
F |
|
Net weight (Kg) |
5,4 |
- Welding cable with electrode holder x 1.8M;
- Earth cable with clamp x 1.2M;
