ARC 140

Brand: Keyue Sub-Cat: MMA Welding Machines

Product description - IGBT technology, the core adopts advanced IGBT inverter device, high frequency - Digital meter to preset and display welding current - Anti-stick, adjustable hot striking, easy to strike the arc, stable arc welding, deep...

Contact

+84902055777

- IGBT technology, the core adopts advanced IGBT inverter device, high frequency

- Digital meter to preset and display welding current

- Anti-stick, adjustable hot striking, easy to strike the arc, stable arc welding, deep weld pool and good welding appearance.

- VRD function is optional, which is safe for welders

- Excellent performance, cart be used for welding with cellulose electrode

- Over current, over heat and under voltage protection is available

- Smaller, lighter and portable, this equipment is protected by a solid metal casing

- Energy saving-compared with the traditional SMAW machine and more efficient

- Suitable for welding the carbon steel, stainless steel, low alloy steel and other metals.

Rated input voltage (V)	1PH AC220±15%
Rated input power (KVA)	5,1
Rated input current (A)	23
Rated output	140A/25,6V
Output current(A)	20-140
No-load voltage (V)	65±5
Rated duty cycle 30 (%) (40°C 10min)	140A
Rated duty cycle 100 (%) (40°C 10min)	77A
Efficiency (%)	70
Protection class	IP21
Insulation class	F
Net weight (Kg)	4.5
