- Contact start system-smooth arc-striking with HF control
- High cutting speed and low cost
- Automatic post-flow stop for rapid re-striking
- Adjustable output current to satisfy the cutting demands based on different kinds of material and thickness of working plate
- Small and smooth cutting seam, little transmutation
- Built-in overheat protection, over voltage protection under voltage protection
- Energy Saving-Compared with the traditional cutting machine and more efficient
|
Rated input voltage (V) |
1PH AC220±15% |
|
Rated input power (KVA) |
5.6 |
|
Rated input current (A) |
25.4 |
|
Rated output |
98V/40A |
|
Output current (A) |
20-40 |
|
No-load voltage (V) |
240 |
|
Rated duty cycle 60(%) (40°C 10min) |
40A |
|
Rated duty cycle 100(%) (40°C 10min) |
31A |
|
Efficiency(%) |
70 |
|
Protection class |
IP21 |
|
Insulation class |
F |
|
Method of arc start |
Contact |
|
Net weight (Kg) |
6.9 |
- Plasma torch
- Earth cable with clamp x 3.0M
- Air pressure regulator
